Kitchen Paper Towel Making Machine

Automatic kitchen paper towel making machine to make kitchen paper roll with embossing, color gluing, spot-spot lamination. It can also make toilet paper roll.

Chat Now Send Inquiry

Description

High-speed manufacturer supply of automatic kitchen paper towel making machine

Equipment description:

Automatic High Speed kitchen paper towel making machine is for toilet paper roll/maxi roll processing and kitchen paper roll production . Machine have core feeding unit, can produce products both with and without core. Raw material from jumbo roll ,after full embossing or edge embossing, color gluing, dot-dot lamination, then perforation, end cutting and spray the tail glue become a log. Then it can working with cutting machine and packing machine to become a full automatic kithcne towel paper production line. The kitchen paper towel making machine is controlled by PLC, people operate it through touch screen, the whole process is automatic, easy to operate, lower the man cost. And Our machine can special-made according to clients' requirements.

Model	1575 Fully Automatic kitchen paper towel making machine
Jumbo Roll Max Width	1800mm (Other size can be specified)
Jumbo Roll Diameter	Φ1500mm(Other size can be specified)
Jumbo Roll Inner Diameter	3inches(76.2mm) (Other size can be specified)
Perforation Distance	4anvil Blades（90-110mm）(Other size can be specified)
Finished Product Diameter	Φ80~φ140mm
Finished Product Core Diameter	φ38~φ55mm
Production Speed	100~250m/min
Program Controller	PLC(Delta)
Unwind Stands	2 Stands（Need to be specified）
Pneumatic System	3HP Air Compressor, Minimum Pressure: 5kg/cm 2Pa （ Provide by user）

Main Power	7.5KW
Dimension	580019001920(LWH)
Weight	About 5.5T (All machine 40mm wallboard type institutions)
Jumbo Roll Layers	1~3layers，14~30gsm
Edge-Line Embossing(can be specified)	Steel to steel (Pneumatic Control)
Embossment (can be specified)	Big diameter rollers,Steel to Rubber, Double Sets
Voltage	380V 50HZ(can be specified)
