A kraft paper tube making machine is an automated industrial system designed to convert multiple layers of kraft paper strips into sturdy, cylindrical tubes. By applying adhesive and winding the paper tightly around a central mandrel, these machines produce tubes of varying thicknesses, diameters, and lengths tailored to specific industry needs.
essential specifications
| Product name | Kraft paper tube making machine |
|
Number of paper winding layers |
3-15 ply |
|
Coiling tube diameter |
20mm--120mm |
|
Coiling tube thickness |
1mm--6mm |
|
Winding head |
Double heads single belt |
|
Cutting method |
Single circular blade cutting |
|
Synchronization control method |
Pneumatic |
|
Glue adding method |
Single-sided /Double-sided gluing |
|
Power |
5.5KW |
|
Human-compute interface |
Color touch screen |
|
Input Power |
380V three-phase four-wire (Other voltage require customization) |
|
Number of operators |
1-2 workers |
|
Coiling tube speed |
3-15m/min |
|
Size |
2600mm×1900mm×1920mm |
|
Total weight |
1600kg |
How It Works
An automated kraft paper tube making machine converts multiple layers of kraft paper strips into sturdy, continuous cylinders through four rapid steps:
1. Unwinding: Multiple kraft paper rolls feed into the machine simultaneously.
2. Gluing: Automated units apply a precise, even layer of adhesive to the strips.
3. Winding: Heavy-duty belts wind the paper tightly around a central steel mandrel.
4. Cutting: A synchronized, servo-driven knife system cuts the moving tube to exact lengths with high precision.
Benefits for Your Business
• 100% Eco-Friendly: Capitalize on the global plastic-free movement with fully recyclable and biodegradable packaging.
• Smart Automation: Modern machines feature PLC touchscreens and servo motor controls for easy operation and minimal material waste.
• High Versatility: A single machine can easily adjust to produce various diameters, thicknesses, and lengths for cosmetics, food, or logistics.
Industry Applications: Who Needs Paper Tubes?
The versatility of kraft paper cylinders makes them indispensable across numerous thriving sectors:
• Cosmetics & Personal Care: Lip balm tubes, and luxury perfume cylinder boxes.
• Food & Beverage: Airtight containers for tea, coffee beans, spices, and potato chips.
• Industrial & Logistics: High-strength shipping tubes, mailing cylinders, and heavy-duty cores for winding stretch film, textiles, and paper tape.
• Gifts & Retail: Elegant apparel packaging, poster tubes, and eco-friendly toy boxes.
