Thermal Paper Roll Making Machine

Application:

The thermal paper roll making machine is mainly applied for cutting various specifications of fax paper, cash register paper, computer bills, medical record paper, POS printing paper, ATM roll paper, film and self-adhesive trademarks and other paper specifications.

Features:

The thermal paper roll making machine adopts the continuous shaft winding method, the winding shaft does not need to use glue or tape paper to connect the paper material, and it is plug-and-play. When producing small-core thermal paper products, it is not only several times faster than ordinary paper. Cutting machine, and the products produced, leaving no traces on the core, clean and beautiful. The slitting specification is controlled by the spliced shim, and any slitting specification can be provided according to the requirements of the manufacturer. (Common specifications for thermal paper products: 44mm, 57mm, 76mm, 80mm, 210mm), and due to the characteristics of surface winding, the winding shaft of the thermal paper roll making machine can use ordinary steel shafts, and the minimum winding diameter can reach 8mm. It is suitable for all kinds of small die roll paper products.

Basic parameters:
Maximum unwinding diameter: 900MM
Inner diameter of tube material paper core: 76MM (3'')
Standard cutting width: greater than 20MM
Maximum receiving diameter: 160MM
Cutting speed: 12---120M/MIN
Total power: 4.5kw
Power supply: 380V 50HZ
Dimensions (L*W*H): 2.5M*1.9M*1.5M
Weight: 800KG
