Toilet paper roll packing machine

Toilet paper roll packing machine can be equipped with an automatic feeding device, and the electronic eye automatically counts and feeds automatically. It can be seamlessly connected with the automatic paper cutter; the machine can pack toilet paper in 2-4-6 rolls, with a ironing machine, and the two ends can be automatically flattened to achieve the effect of manual packaging.

Technical parameter of toilet paper roll packing machine

Model:MJ-200

Capacity:30-50 bags/min

Single roll size: Diameter: 90-120mm

              Length：90-100mm

Packing range:2,4 and 6 rolls

Power:6kw

Air compressor:0.5Mpa

Packing material:CPP film

Voltage:220v/50hz

Weight:1500kg

Dimension:8000*1200*1750mm

Feature of toilet paper roll packing machine

1. It adopts programmable logic controller (PLC) control to reduce mechanical contacts, low system failure rate and more stable and reliable operation;

2. Frequency control, change the packaging speed, just rotate the potentiometer knob connected to the inverter.

3. This machine adopts a toothed chain type continuously variable transmission, which can change the length of the bag by rotating the handle;

4. Digital display function, which can directly display bag length, packaging speed, sealing temperature, output, etc.

5. Two-way photoelectric tracking system can ensure that the film is cut at the required position and the cutting point is accurate;

6. Automatic positioning and parking function can ensure that the film will not be burned when the machine is stopped.

7. The leakage protection switch installed in this machine can ensure the safety of people and machines.

8. There is an emergency stop switch and a shield at the front of the sealing knife to prevent the operator from injuring the hand during misoperation.

More details

If u r interested, welcome to contact us!
